| 1 |
RATED HORSE POWER |
(12bhp) 8.82KW |
| 4 |
RATED R.P.M. |
680 |
| 3 |
CYLINDER BORE X STROKE |
114.3 mm x139.7 mm(4.5"x 5.5") |
| 4 |
NO. OF CYLINDER |
TWIN |
| 5 |
FUEL INJECTION EQUIPMENTS |
MICO(BOSCH) |
| 6 |
FUEL OIL |
L.D.O./H.S.D.O. |
| 7 |
LUBRICATING OIL |
SAE-30 |
| 8 |
FUEL CONSUMPTION AT FULL LOAD |
227 gms/bhp-hr |
| 9 |
LUBRICATING OIL CONSUMPTION |
35 HOURS/LITER |
| 10 |
LUBRICATION SYSTEM |
SPLASH AND PUMP SYSTEM |
| 11 |
ROTATION OF ENGINE |
CLOCKWISE FACING FLYWHEEL AND KEEPING EXHAUST ON LEFT HAND SIDE |
| 12 |
BEARINGS |
BUSH BEARING ALSO AVAILABLE IN TAPER ROLLER BEARINGS AGAINST ORDER |
| 13 |
WEIGHT OF THE ENGINE BAREWEIGHT OF THE ENGINE GROSS |
490 Kgs.630 Kgs. |
| 14 |
MEASUREMENT OF THE CASE |
1540mmX740mmX1150mm |
| 15 |
STANDARD ACCESSORIES |
(1)FUEL TANK WITH COCK AND PIPE,(2)AIR CLEANER,(3)EXHAUST SILENCER,(4)STARTING HANDLE,(5)SCREW DRIVER,(6)SPANER SET,(7)OIL CAN,(8)FOUNDATION BOLTS,(9)INSTRUTION BOOK.
|
| 1 |
RATED HORSE POWER |
(16bhp) 11.76KW |
| 4 |
RATED R.P.M. |
850 |
| 3 |
CYLINDER BORE X STROKE |
114.3 mm x139.7 mm(4.5"x 5.5") |
| 4 |
NO. OF CYLINDER |
TWIN |
| 5 |
FUEL INJECTION EQUIPMENTS |
MICO(BOSCH) |
| 6 |
FUEL OIL |
L.D.O./H.S.D.O. |
| 7 |
LUBRICATING OIL |
SAE-30 |
| 8 |
FUEL CONSUMPTION AT FULL LOAD |
227 gms/bhp-hr |
| 9 |
LUBRICATING OIL CONSUMPTION |
26 HOURS/LITER |
| 10 |
LUBRICATION SYSTEM |
SPLASH AND PUMP SYSTEM |
| 11 |
ROTATION OF ENGINE |
CLOCKWISE FACING FLYWHEEL AND KEEPING EXHAUST ON LEFT HAND SIDE |
| 12 |
BEARINGS |
BUSH BEARING ALSO AVAILABLE IN TAPER ROLLER BEARINGS AGAINST ORDER |
| 13 |
WEIGHT OF THE ENGINE BAREWEIGHT OF THE ENGINE GROSS |
530 Kgs.670 Kgs. |
| 14 |
MEASUREMENT OF THE CASE |
1540mmX740mmX1150mm |
| 15 |
STANDARD ACCESSORIES |
(1)FUEL TANK WITH COCK AND PIPE,(2)AIR CLEANER,(3)EXHAUST SILENCER,(4)STARTING HANDLE,(5)SCREW DRIVER,(6)SPANER SET,(7)OIL CAN,(8)FOUNDATION BOLTS,(9)INSTRUTION BOOK.
|
