| 1 |
RATED HORSE POWER
|
(6bhp) 4.41 KW
|
| 4 |
RATED R.P.M.
|
680
|
| 3 |
CYLINDER BORE X STROKE
|
114.3 mm x139.7 mm(4.5"x 5.5")
|
| 4 |
NO. OF CYLINDER
|
SINGLE
|
| 5 |
FUEL INJECTION EQUIPMENTS
|
MICO(BOSCH)
|
| 6 |
FUEL OIL
|
L.D.O./H.S.D.O.
|
| 7 |
LUBRICATING OIL
|
SAE-30
|
| 8 |
FUEL CONSUMPTION AT FULL LOAD
|
309 GMS/kw-hr
|
| 9 |
LUBRICATING OIL CONSUMPTION
|
70 HOURS/LITER
|
| 10 |
LUBRICATION SYSTEM
|
SPLASH SYSTEM
|
| 11 |
ROTATION OF ENGINE
|
CLOCKWISE FACING FLYWHEEL AND KEEPING EXHAUST ON LEFT HAND SIDE
|
| 12 |
BEARINGS
|
TAPER ROLLER BEARING ALSO AVAILABLE IN BUSH BEARINGS WITH PUMP AGAINST
ORDER
|
| 13 |
WEIGHT OF THE ENGINE BARE
WEIGHT OF THE ENGINE GROSS
|
320 Kgs.
418 Kgs.
|
| 14 |
MEASUREMENT OF THE CASE
|
1140mmX740mmX1100mm
|
| 15 |
STANDARD ACCESSORIES
|
(1)FUEL TANK WITH COCK AND PIPE,(2)AIR CLEANER,(3)EXHAUST SILENCER,(4)STARTING
HANDLE,(5)SCREW DRIVER,(6)SPANER SET,(7)OIL CAN,(8)FOUNDATION BOLTS,(9)INSTRUTION
BOOK.
|
| 1 |
RATED HORSE POWER
|
(8bhp) 5.88KW
|
| 4 |
RATED R.P.M.
|
850
|
| 3 |
CYLINDER BORE X STROKE
|
114.3 mm x139.7 mm(4.5"x 5.5")
|
| 4 |
NO. OF CYLINDER
|
SINGLE
|
| 5 |
FUEL INJECTION EQUIPMENTS
|
MICO(BOSCH)
|
| 6 |
FUEL OIL
|
L.D.O./H.S.D.O.
|
| 7 |
LUBRICATING OIL
|
SAE-30
|
| 8 |
FUEL CONSUMPTION AT FULL LOAD
|
309 GMS/kw-hr
|
| 9 |
LUBRICATING OIL CONSUMPTION
|
53 HOURS/LITER
|
| 10 |
LUBRICATION SYSTEM
|
SPLASH SYSTEM
|
| 11 |
ROTATION OF ENGINE
|
CLOCKWISE FACING FLYWHEEL AND KEEPING EXHAUST ON LEFT HAND SIDE
|
| 12 |
BEARINGS
|
TAPER ROLLER BEARING ALSO AVAILABLE IN BUSH BEARINGS WITH PUMP AGAINST
ORDER
|
| 13 |
WEIGHT OF THE ENGINE BARE
WEIGHT OF THE ENGINE GROSS
|
375 Kgs.
440 Kgs.
|
| 14 |
MEASUREMENT OF THE CASE
|
1140mmX740mmX1100mm
|
| 15 |
STANDARD ACCESSORIES
|
(1)FUEL TANK WITH COCK AND PIPE,(2)AIR CLEANER,(3)EXHAUST SILENCER,(4)STARTING
HANDLE,(5)SCREW DRIVER,(6)SPANER SET,(7)OIL CAN,(8)FOUNDATION BOLTS,(9)INSTRUTION
BOOK.
|
